| 600
lbs |
ANSI
B 16.5 |
| Diâmetro
Nominal |
D |
F |
N°
de Parafusos |
Diâmetro
dos Parafusos |
Comprimento
L (mm) |
| Prisioneiros |
Parafuso |
| Pol. |
mm |
mm |
d
(pol) |
Ressalto
1/16" |
Ring-Joint |
Ressalto
1/16" |
| 1/2" |
66,7 |
16,0 |
4 |
1/2 |
76,0 |
70,0 |
76,0 |
| 3/4" |
82,5 |
19,0 |
4 |
5/8 |
82,5 |
76,0 |
82,5 |
| 1" |
88,9 |
19,0 |
4 |
5/8 |
89,0 |
82,5 |
89,0 |
| 1.1/4" |
98,4 |
19,0 |
4 |
5/8 |
95,0 |
89,0 |
95,0 |
| 1.1/2" |
114,3 |
22,0 |
4 |
3/4 |
101,5 |
95,0 |
101,5 |
| 2" |
127,0 |
19,0 |
8 |
5/8 |
101,5 |
95,0 |
108,0 |
| 2.1/2" |
149,2 |
22,0 |
8 |
3/4 |
114,5 |
108,0 |
120,5 |
| 3" |
168,3 |
22,0 |
8 |
3/4 |
120,5 |
114,5 |
127,0 |
| 3.1/2" |
184,1 |
25,5 |
8 |
7/8 |
133,5 |
127,0 |
139,5 |
| 4" |
215,9 |
25,5 |
8 |
7/8 |
139,5 |
133,5 |
146,0 |
| 5" |
266,7 |
28,5 |
8 |
1 |
159,0 |
152,5 |
165,0 |
| 6" |
292,1 |
28,5 |
12 |
1 |
165,0 |
159,0 |
171,5 |
| 8" |
349,2 |
32,0 |
12 |
1.1/8 |
190,5 |
184,0 |
197,0 |
| 10" |
431,8 |
35,0 |
16 |
1.1/4 |
209,5 |
203,0 |
216,0 |
| 12" |
489,0 |
35,0 |
20 |
1.1/4 |
216,0 |
209,5 |
222,0 |
| 14" |
527,0 |
38,0 |
20 |
1.3/8 |
228,5 |
222,0 |
235,0 |
| 16" |
603,2 |
41,5 |
20 |
1.1/2 |
247,5 |
241,5 |
254,0 |
| 18" |
654,0 |
44,5 |
20 |
1.5/8 |
266,5 |
260,5 |
273,0 |
| 20" |
723,9 |
44,5 |
24 |
1.5/8 |
286,0 |
279,5 |
292,0 |
| 24" |
838,2 |
51,0 |
24 |
1.7/8 |
324,0 |
317,5 |
336,5 |
|
